The LyonForge 12" Neodymium Mid/Bass Driver combines compact design with powerful, precise sound. Delivering 600 watts of continuous power and 300 watts AES, it provides reliable performance for both midrange and low-end applications. Its frequency response of 54 Hz to 3 kHz ensures clear, accurate reproduction across mid and bass frequencies, making it ideal for PA systems, studio monitors, and live sound setups.Equipped with advanced neodymium magnets, this driver offers high efficiency, lighter weight, and enhanced sensitivity, making installation and transport easier without compromising output. The neodymium design also improves heat resistance, ensuring stable performance during extended use. Durable and engineered for professional applications, the LyonForge 12" Neodymium Mid/Bass Driver delivers dynamic, precise, and dependable sound.
Nominal Diameter: 315mm/ 12 inch Frame: Aluminium Magnet: Neodymium Magnet Diameter: 74mm Nominal Impedance: 8 Ohm Magnetic Gap Depth: 11.3mm AES Power Handling: 300W Continuous Program Power: 600W Sensitivity 1W/1M: 95.7dB Frequency Range: 54-3kHz Voice Coil Diameter: 75.5mm/ 3 inch Former Material: TIL Winding Depth: 17mm Surround (Damper): Conex Cone and Dust Cap: Paper Surround Material: Polycotton Surround Design: Double-roll Rosonanco Frequency: Fs, 54Hz DC Resistance: Re, 7.2 Ohms Mechanical Factor: Qms, 6.248 Electrical Factor: Qes, 0.368 Total Factor: Qts, 0.348 BL Factor: BL, 19.891T.m Effective Moving Mass: Mms, 59.5gr Compliance: Cms, 145.21 µ M/N Equivalent Cas Air Load: Vas 56.356L Effective Piston Area: Sd, 0.052m² ? (Eta Zero): ?0, 2.348% Overall Diameter: 315mm Bolt Circle Diameter: 295mm Baffle Cutout Diameter: 285mm Depth: 145mm Neight Weight: 3.9kg Shipping Weight: 4.5kg
