Audio Signal Distribution Splitter 2 Inputs to 12 Outputs

Code: SPAD-6
Availability: In Stock
  • Up To 12 Outputs From 1 Or 2 Inputs
  • Individual Volume Control For Each Output
  • Input Peak LEDS
£95.90 inc VAT
Add

Signal splitter with 2 line inputs which are buffered and divided across 6 outputs each. Can be used as a 6-way stereo splitter or can be switched as a mono system feeding all 12 outputs from input A. Applications include zone mixing, personal monitoring, effects patching and routing in complex recording setups.

Power supply:115/230Vac, 50/60Hz (IEC)
Inputs:A & B, (6.3mm jack)
Outputs:1 - 6 & 7 - 12 (6.3mm jack)
Input impedance:20k Ohms
Output impedance:220 Ohms
Frequency response:20Hz - 20kHz, +0/-1dB
Signal to noise ratio:>95dB
THD:<0.008%
Dimensions:483 x 44 x 170mm
Weight:2.0kg
