DANTE DBI-04 Network Audio Bridge 4 Outputs & GPIO Ports Install Version

Code: DBI04
Availability: In Stock-Delivery 5-7 days
  • Converts Dante®/AES67 network audio to 4 high-grade balanced analog outputs
  • Gigabit Ethernet I/O with high-speed Marvell switch, no linking delays
  • Built-in DSP: parametric EQs, compressors, delays on all channels
  • 8×8 audio matrix for flexible routing and local premix
  • Integrated web server with intuitive graphical interface
  • SYNQ Network Discovery Tool for easy network setup
  • OSC protocol support for mobile, tablet, and desktop control
  • Exceptional audio quality: S/N >120 dB, THD <0.003%
  • GPI/GPO ports for switches, potentiometers, alarms, external triggers, and control
  • EUROBLOCK connectors for quick and secure installation
  • Power options: external 24 VDC (EUROBLOCK) or PoE (Class 0)
  • ½-width 19? die-cast chassis; single or dual unit rack mount, optional wall mount
£495.00 inc VAT
Add

The Sync DBI-04 is a premium analogue to Dante® network audio bridge designed for fixed installations, providing exceptional audio quality and flexibility. It converts Dante® and AES67 network audio to four high-grade balanced analogue outputs while offering full DSP processing—including parametric EQs, compressors, and delays on all channels. The integrated 8×8 audio matrix allows flexible routing and local premix, making it ideal as a Dante-enabled speaker management processor or for a wide range of other audio applications.

Setup and control are effortless via the built-in web server and the SYNQ Network Discovery Tool, which allows instant device access without IP knowledge. OSC protocol support enables control from smartphones, tablets, and desktop computers. Industrial-grade components ensure high reliability, while multiple power options and flexible mounting solutions make installation straightforward.
